Amflow PL Carbon 800Wh Satin Silver

$9,399.00

Size

M L XL XXL
Thumbnail for Amflow PL Carbon 800Wh Satin Silver Thumbnail for Amflow PL Carbon 800Wh Satin Silver Thumbnail for Amflow PL Carbon 800Wh Satin Silver Thumbnail for Amflow PL Carbon 800Wh Satin Silver Thumbnail for Amflow PL Carbon 800Wh Satin Silver
Amflow PL Carbon 800Wh Satin Silver
Amflow PL Carbon 800Wh Satin Silver
Amflow PL Carbon 800Wh Satin Silver
Amflow PL Carbon 800Wh Satin Silver
Amflow PL Carbon 800Wh Satin Silver

Amflow PL Carbon 800Wh Satin Silver

Size

M L XL XXL
$9,399.00

PLEASE NOTE:

  • This product is Store Pickup Only (Rosebud Vic).
  • Order online, pickup in store.
  • Shipping not available.
  • Special Order Item - stock will be transferred from supplier following your confirmed order.
PRODUCT DESCRIPTION

The Amflow PL electric mountain bike offers 850 watts of peak power in an ultra-light build weighing 19.2 kg. [1] With its unrivaled combination of power, range, weight, and intelligent features, this groundbreaking eMTB is built for the trailblazers.







A full-power eMTB with a stunningly lightweight body. Meticulously designed and crafted to deliver the ultimate ride.


Amflow PL's ultra-light carbon fiber frame weighs just 2.27 kg, [2] for breathtaking speed and agility.






Max Continuous Torque - 105 N·m





M1 Drive Unit Weight - 2.52 kg


  • Peak Power 850 W



  • Drive Assistance Powerful Drive, Smooth Assistance


Designed and manufactured by DJI, the Avinox Drive System is seamlessly integrated into Amflow PL, infusing the type of cutting-edge hardware and software that has made DJI an industry leader in drones and camera stabilization technology. The Avinox M1 Drive Unit features a compound planetary gearset with an industry-leading power-to-size ratio.

The durable, high-strength polymer material inside the Avinox M1 Drive Unit effectively suppresses noise during high-speed gearbox operation. With multiple precision sensors built-in, combined with advanced DJI algorithms, it provides a strong, smooth assistance for a wide range of scenarios and conditions.


800Wh - Range: 157km - Weight: 3.74kg

  • 600Wh Range 117km - Weight: 2.87kg

AMFLOW PL CARBON | 800WHAmflow PL CarbonDrive Unit: Avinox M1 Drive Unit | 105 N·m
Battery: Avinox Integrated Battery | 800wh
Display: Avinox Screen | 2-inch OLED Touch Control Display


Handlebar: Amflow Enduro Alloy
Stem: Amflow Enduro Stem, One-piece CNC
Shifters: SRAM GX Eagle Trigger Shifter
Brakes: Magura MT5
Saddle: Selle Royal SRX Plus
Seatpost: KS Rage-i | M: 150mm | L: 170mm | XL/XXL: 190mm


Wheels: Amflow HMA-30 | 29″
Front Tire: Maxxis Assegai MaxxTerra 29×2.5″ WT 3C EXO E-25 TLR
Rear Tire: Maxxis Dissector MaxxTerra 29×2.4″ WT 3C EXO+ E-25 TLR


















Derailleur: SRAM GX Eagle 12-speed
Crankset: DJI Avinox SL Crank
Cassette: SRAM PG-1230, 11-50T
Chain: SRAM NX Eagle



GEOMETRY







































































































































M L XL XXL
A Reach
452mm

475mm

500mm

525mm
B Stack Height
618mm

628mm

641mm

655mm
C Standover Height
780mm

785mm

790mm

795mm
D Front Center
782mm

810mm

844mm

873mm
E Fork Length
570mm

570mm

570mm

570mm
F Wheelbase
1227mm

1255mm

1289mm

1318mm
G Chainstay Length
445mm

445mm

445mm

445mm
H Bottom Bracket Drop
29mm

29mm

29mm

29mm
I Bottom Bracket Height
345.5mm

345.5mm

345.5mm

345.5mm
J Effective Top Tube Length
595mm

620mm

648mm

676mm
K Head Tube Angle
64.5°

64.5°

64.5°

64.5°
L Head Tube Length
105mm

115mm

130mm

145mm
M Actual Seat Tube Angle
70°

70°

70°

70°
N Effective Seat Tube Angle
77°

77°

77°

77°
O Seat Tube Height
430mm

450mm

470mm

500mm





ax nhttps://video.amflowbikes.com/video_trans/494fc5e5ac774377ba88730e4e0c0218/webclip.mp4uous Torque


105 N·m




M1 Drive Unit Weight


2.52 kg [2]




Peak Power


850 W
