FRAME |
ONE-SIXTY LITE III; 171 STR mullet; MAT aluminium; 29x2.5" max. WHS; 148x12 AST; BSA BBR |
SHOCK |
DVO Jade X D3; coil; spring rate:XS, S:300 M:350 L:400 XL:450 |
FORK |
SR Suntour Durolux 38 RC; Air; 180 STR; Tapered; xxmm fork offset; 29x2.60" max. WHS |
Tektro Gemini HD-M535; 4 piston |
Tektro Gemini HD-M535; 4 piston |
Tektro TR203-45; 203mm |
Tektro TR203-45; 203mm |
CHAIN |
KMC xGlide |
CHAINGUARD |
MERIDA EXPERT TR ISCG05 |
CHAINWHEEL |
MERIDA Expert TR II; 32 ATC |
CRANK/SIZE |
165 mm for all sizes |
BB SET |
Samox BSA 24mm EB2401 |
|
Shimano CUES U6000; GS |
FREEWHEEL |
Shimano LG300; 11-48 ATC; 10 GER |
PEDAL |
|
GRIP |
MERIDA COMP EC |
H-BAR |
MERIDA EXPERT TR II; MAT aluminium; 780 WHB; XS/S 18 RHB; M/L/XL 30 RHB |
H-B STEM |
MERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD |
H-STEM/SIZE |
40 mm |
Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
Shimano TC500-HM-B; 148x12 WHR; 32 SPH; Centerlock |
MERIDA COMP TR; including removeable lever, 6/4mm allen key |
RIM |
MERIDA COMP TR II; 110x15 WHF; 148x12 WHR; 28 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); front 29"; rear 27.5" |
SADDLE |
MERIDA COMP SL; 25% recycled material; V-mount |
SEAT CLAMP |
MERIDA EXPERT |
SEAT POST |
Shimano SL-MT500-L |
Shimano CUES U6000 |
Continental Kryptotal-F; 29x2.4"; fold; TR; Enduro casing; Soft Compund |
Continental Kryptotal-R; 27.5x2.4"; fold; TR; Enduro Casing; Soft Compound |
BOTTLE CAGE |
|
E-SHIFT PARTS-1 |
|
OTHER 1 |
Rear Brake Adapter PM 200mm to 203mm rotor |
OTHER 2 |
|
OTHER 3 |
|
OTHER 4 |
|
OTHER 5 |
|
