Engineered using the same technology and design process as NorcoÕs top-tier trail bikes, the Fluid FS delivers exceptional performance and value for riders ready to explore everything the trail has to offer. ItÕs a bike designed to help you ride farther, push harder, and have more fun on every ride. Praised across the industry, the Fluid FS has earned PinkbikeÕs Value Bike of the Year, Vital MTBÕs Bike of the Year, and Bicycling MagazineÕs Best Value Trail Bike. With refined geometry, durable components, and excellent suspension performance, it offers confidence and capability well beyond its price point. Available in five frame sizes and designed to fit riders from 5'1" to 6'7", the Fluid FS features boutique-level fit and finish along with size-specific dropper posts and a low-slung top tube that creates plenty of room to move on technical terrain.
Key Features
- Lightweight 6061 aluminum trail frame with 130mm rear travel
- 140mm RockShox Recon RL fork for confident trail handling
- Shimano CUES 10-speed drivetrain with wide-range gearing
- Powerful 4-piston hydraulic disc brakes
- Long-travel size-specific dropper posts
- 29Ó wheels with aggressive trail tyres
- Ride Alignedª design for optimized fit and performance
Specifications
-
Frame:6061 Aluminum Frame, 130mm Travel, UDH, Eagle Transmission Compatible, Ride Alignedª
-
Fork:RockShox Recon RL, 140mm Travel, 44mm Offset
-
Rear Shock:X-Fusion O2 Pro R AV, 210x50mm
-
Headset:Sealed Bearing, Tapered 1-1/8" Ð 1.5" (ZS44/28.6 | ZS56/40)
-
Shifter:Shimano CUES SL-U6000, 10 Speed
-
Rear Derailleur:Shimano CUES LG-500, 10 Speed
-
Cassette:Shimano CUES LG-400, 11-48T, 10 Speed
-
Chain:Shimano LG-500, 10 Speed
-
Crankset:Shimano CUES FC-U6000, 30T Ñ 170mm (S) / 175mm (M-XXL)
-
Bottom Bracket:Shimano BB-MT501, BSA 73mm
-
Front Brake:Tektro HD-M535, 4-Piston, Resin Pads
-
Front Rotor:TRP TR180, 180mm, 2.3mm Thickness, 6-Bolt
-
Rear Brake:Tektro HD-M535, 4-Piston, Resin Pads
-
Rear Rotor:TRP TR180, 180mm, 2.3mm Thickness, 6-Bolt
-
Handlebar:Norco 6061 DB Alloy, 800mm Width, 25mm Rise
-
Stem:Norco 6061 Alloy, 40mm Length, 35mm Clamp
-
Grips:Propalm Pro, 130mm Length
-
Saddle:Norco Trail
-
Seatpost:TranzX YSI34 Dropper, 34.9mm Ñ 150mm (S) / 170mm (M) / 200mm (L,XL,XXL)
-
Seatpost Clamp:Norco Alloy Nutted Clamp, 38.5mm
-
Front Hub:Formula DC-511, 15x110mm Boost, 32H, 6-Bolt
-
Rear Hub:Formula DC-3248, 12x148mm Boost, HG, 32H, 6-Bolt
-
Rims:WTB ST, 30mm Internal Width, 32H, 29"
-
Front Tire:Continental Kryptotal-F Trail, Endurance, 29 x 2.4", Folding
-
Rear Tire:Continental Xynotal Trail, Endurance, 29 x 2.4", Folding
-
Spokes:Stainless Steel, 14G
