FRAME |
REACTO CF3 IV; MAT carbon; 700x30C max. WHS; 100x12/ 142x12 AST; BB86,5 BBR |
FORK |
REACTO CF3 IV DISC; MAT carbon; 700x30C max. WHS |
BRAKE LEVER |
Sram ED Rival eTap AXS |
Sram ED Rival eTap AXS; Hydraulic disc |
Sram ED Rival eTap AXS; Hydraulic disc |
Sram DB ROTOR CENTERLOCK PACELINE; 160mm |
Sram DB ROTOR CENTERLOCK PACELINE; 160mm |
C-HOUSING |
|
CHAIN |
SRAM Rival 12s |
CHAINWHEEL |
Sram Rival eTap AXS ; 48-35 ATC; Power Meter |
CRANK/SIZE |
165 mm-XXS, 170 mm-XS, 172.5 mm-S/M/L, 175 mm-XL |
BB SET |
Sram Pressfit Dub, Presfit 86.5 |
Sram Rival eTap AXS |
Sram Rival eTap AXS; SS |
FREEWHEEL |
Sram CS XG 1250 D1; 10-36 ATC; 12 GER |
PEDAL |
|
GRIP |
MERIDA ROAD Expert |
HANDLEBAR |
Metron Aero Bar; MAT carbon; 380mm (XXS-XS-S); 400mm (M-L-XL) |
H-B STEM |
EXPERT SL 2PII; MAT aluminium; -9 ASD |
H-STEM/SIZE |
90mm-XXS/XS, 100 mm-S, 110 mm-M/L, 120 mm-XL |
|
|
MERIDA EXPERT SL |
MERIDA EXPERT SL; including removable lever; 6/4mm allen key |
RIM |
Vision SC55 Disc brake; 100x12 WHF; 142x12 WHR; 19 IWR; 55 HRI; Centerlock; MAT carbon |
SADDLE |
MERIDA EXPERT SL; 6% recycled and 23% nature material; V-mount; incl. MERIDA minitool |
SEAT CLAMP |
MERIDA REACTO Aero |
SEAT POST |
MERIDA Team CW; Aero shape; 15 SSB; Carbon |
Sram Rival eTAP AXS HRD |
Sram Rival eTAP AXS HRD |
Continental Grand Prix 5000S TR; 700x28C; fold; tubeless ready |
Continental Grand Prix 5000S TR; 700x28C; fold; tubeless ready |
E-SHIFT PARTS-2 |
|
E-SHIFT PARTS-3 |
|
OTHER 5 |
MERIDA Multitool with saddlebox |
