FRAME |
eSPEEDER LITE III; MAT aluminium; 700x45C / 700x42C (with fender) / 27,5x47C max. WHS; 100x9/135x9 AST; BSA BBR |
SHOCK |
|
FORK |
MERIDA SILEX CF2; carbon; max. 700x42C / 700x35C (with fender) / max. 50x650B WHS |
Sram Apex |
Sram Apex |
Sram Centerline; 160mm |
Sram Centerline; 160mm |
CHAIN |
Sram SX Eagle |
CHAINWHEEL |
Sram Apex 1 Wide Crankset; 40 ATC |
CRANK/SIZE |
170 mm-XS/S/SM/ML, 175 mm-L/XL |
BB SET |
Sram DUB BSA 68 Road Wide |
|
Sram Apex Eagle |
FREEWHEEL |
Sram PG-1210 Eagle; 11-50 ATC; 12 GER |
PEDAL |
VP VPE-891 |
GRIP |
MERIDA ROAD EXPERT |
H-BAR |
MERIDA EXPERT GRII; MAT aluminium; 400mm (XS-S) , 420mm (M) , 440mm (L/XL) |
H-B STEM |
MERIDA TEAM CC III; MAT aluminium; 31.8 DSH; -6 ASD |
STEM/SIZE |
80 mm all sizes |
HEAD SET |
MERIDA 8158 |
Shimano HB-TC500; 100x12 WHF; 28 SPH; Centerlock |
|
MERIDA EXPERT SL |
|
RIM |
MERIDA EXPERT CX; 19 IWR; 24 HRI; MAT aluminium; Tubeless ready (tubeless tape and valves not included) |
RIM TAPE |
|
SADDLE |
MERIDA COMP SL; V-mount; incl. MERIDA minitool |
SEAT CLAMP |
MERIDA EXPERT |
SEAT POST |
MERIDA EXPERT CC; MAT carbon; 30.9 DSP; 0 SSB |
|
|
INNER TUBE |
Lite |
Maxxis Rambler; 650Bx47; ShieldWall / TLR |
|
BOTTLE CAGE |
BOTTLE CAGE ADAPTER, BK-003 |
CARRIER |
|
FENDER |
|
KICKSTAND |
|
CG-119PG-BLACK(1) |
CG-404RG-BLK |
FRAME LOCK |
|
DRIVE UNIT |
Mahle X30 Drive Unit |
DRIVE COVER |
|
BATTERY |
Mahle ix250Wh Battery Pack; 250Wh |
BATTERY CHARGER |
Mahle X30 Charger |
BATTERY LOCK |
|
DISPLAY |
|
